Internally Fed Drum Screen (IFD)
Drum-type screen for septage receiving
The Internally Fed Drum Screen (IFD) is a screen fed from the inside, self-cleaning, suitable for a variety of applications, from the screening of sludge receiving tanker trucks to industrial processes.
MANUFACTURER
Simeco
APPLICATION
Septage receiving and other concentrated waste streams such as:
- Papermill
- Food Industry
- Slaughterhouses
- Industrial plants
ADVANTAGES
- screen can be perforated plate or wedge wire
- can screen concentrated waste streams
- double washing system unclogs screen
- screenings conveyed to the outlet by a screw inside the drum
Downloads
Downloads
The IFD consists of a cylindrical drum screen, which can be perforated plate or wedgewire, rotated by a drive.
The inlet pipe ends inside the drum and a special distrubuting system distributes the wastewater along the drum.
A double washing system prevents clogging of the screen. An internal screw conveys screenings to the outlet.
