DVS Cable-Rake Bar Screen

Fixed bar screen with cable-operated rake cleaning mechanism



The DVS Cable Rake Bar Screen is used to pre-screen sludge and septage from tanker trucks. It consists of a fixed bar screen installed in the septage receiver chanell, which is periodically cleaned by a rake mechanism lowered and raised from the surface.

MANUFACTURER

EMO | Environment by Technology (France)

APPLICATION

  • Septage receiving
  • Small municipal WWTP inlet works
  • Coarse screening for small industrial facilities

ADVANTAGES

  • Coarse bar screen only captures large material and thus generally does not require accompanying washing/dewatering equipment
  • Performance not impacted by presence of large stones
  • All mechanical / moving parts are situated above the water level
  • Available in front-rake or back-rake configurations
Downloads
Downloads

 Download DVS Brochure

The DVS screen is installed into the channel with the bar screen at the bottom and the cable rake mechanism at rest in the header box above the operating floor. When septage screenings collect on the bar screen in the channel, the open rake is lowered (either manually or automatically based on water level) from the header box down into the channel. When the rake reaches the material trapped on the bar screen, it closes and traps the screenings between the rake and the screen. The rake then raises, bringin the screenings with it back to the surface. the screenings are then discharged into a surface-level screenings bin by an ejector blade in the header box.
